[Cobra 76 two]

I made this jig for bending spring wire to make a good, easy to install retaining wire (shepard's crook) in my Saiga conversions.
This retainer can be installed and removed easily with no tools.
First I put the straight part of the factory spring in a vice and stick a steel rod thru the coils.
Then grab the rod with both hands and pull to staighten out the wire.
Number of downloads: 34

Make a loop on one end and put that over the stud on the jig.
Number of downloads: 28
Tighten wingnut to hold in place.
Wrap wire around the next screw and put a bend in it.
Wrap around the next screw to complete the retainer shape.
Number of downloads: 21
Number of downloads: 18
Number of downloads: 17
Wrap around one more time to make a loop for the next one.
Number of downloads: 16
Cut it and start over.
Number of downloads: 15
There should be enough left for another retainer.
Number of downloads: 15


It installs like this, but on the left inside of the receiver.
Number of downloads: 36  IMAG0024.JPG (83.03K)
Number of downloads: 31

Front loop on the floor, wire under hammer pin groove, then over trigger pin groove.
Push down on the top loop, flexing the wire and insert the end of the safety selector axle thru the loop and into it's hole in the left side of receiver.
Lock it down and your done.

[inparidel]

Very cool. Or, just leave the factory wire where it is on its own little axis pin (see other thread response for tech details).

This post has been edited by inparidel: 07 July 2006 - 01:35 PM

[dinzag]

Thanks buddy! Sweet Idea!

That's going to the Tech Section...

[Cobra 76 two]

You're welcome sir!
It's already there...lol

[G O B]

G O B

[nyclu3]

Cobra,

Would it be easier to use the Tapco retaining plate coz I really hate fooling with the spring . I want to use something better for my S-12. gonna try to order from Pvt. Pyle when I get back to NY. Also, thanks for the Sauces, they got there today sometime . I'll let you know how it is when I try them

I'm gonna try to construct the same jig and let you know how it is.

Thanks again,

nyclu3

[WA-Tom]

Pics are good, but how about some dimensions?

[nalioth]

WA-Tom, on 30 May 2010 - 12:55 AM, said:

Pics are good, but how about some dimensions?

Make your own L-wire retainer
